PROTECTION OF PRE-INSULATED EXPOSED PIPES WITH TIAL-LCP
TIAL - LCP is a heat-shrinkable tape designed for protection of pre-insulated exposed pipes. Coating of straight pipes, bends and fittings is performed by spiral winding in field conditions.
Pre-insulation of pipes can be provided with PU foam, mineral cotton and other heat-insulating materials and then with TIAL-LCP tapes for waterproofing.
TIAL-LCP provides long lasting and effective protection of heat insulation layer against water, UV-radiation, and other external factors. Unique property of TIAL-LCP is fire-resistance. This property allows to greatly minimize damage caused by burning dried grass or in case of incendiary crime.
For good-looking appearance of above-ground district heating pipes TIAL provides customers with TIAL-LCP of various colors (silver, green, blue, red and yellow).
Coating works can be performed by application crews of 2 or 3 workers depending on the pipeline diameter.
Protective properties of TIAL-LCP are preserved at temperatures from - 60 °C to +60 °C.
Lifetime of TIAL-LCP is minimum 30 years.
BENEFITS
fire-resistant
good-looking exterior appearance
long-lasting protection
opportunity to preserve and restore existing heat insulated layer
